| Particulars |
Android |
Windows |
| Screen Size |
11.6” HD Brightness : 220-250nits |
11.6” HD Brightness : 220-250nits |
| Resolution |
1366*768 |
1366*768 |
| Interface Type |
EDP |
LVDs & EDP |
| Touchscreen |
PCAP, Multitouch, USB |
PCAP, Multitouch, USB |
| Motherboard |
RK3566, Quad-core A55 CPU - 2.0Ghz |
Gemini Lake J4125 CPU - 2.0Ghz |
| Ram |
2Gb Ram -DDR4 (Optional 4Gb) |
4Gb Ram -DDR4 (Optional 8Gb) |
| EMMC |
16Gb EMMC (Optional 32Gb ) |
128Gb SSD |
| Operating System |
Android 11 with GMS |
Windows 10, 11 OS Support |
| Dual Display Support |
No |
Yes, 11.6" through HDMI |
| Interfaces |
| LAN |
100M |
1000M |
| USB |
2 |
2 |
| HDMI |
- |
1 |
| RS232 |
1 |
1 |
| Micro USB |
1 |
1 |
| Audio |
1 |
1 |
| Cash Drawer |
Extended from Printer |
Extended from Printer |
| Communication |
| Wi-Fi |
2.4 & 5.0G |
2.4 & 5.0G |
| Bluetooth |
4.2 |
5.0 |
| Storage Temp |
0 to 40oc Storage |
0 to 40oc Storage |
| Operating Temp |
(-10oc – 50oc) |
(-10oc – 50oc) |
| Power Adapter |
24V, 2.5A |
24V, 4A |
| POS Printer |
| Printer Type |
Thermal Paper |
Thermal Paper |
| Print Speed |
170mm/sec |
170mm/sec |
| Mechanism type |
CAPD347C Seiko Comptatible |
CAPD347C Seiko Comptatible |
| Cutter |
Chinese , Partial Cut |
Chinese , Partial Cut |
| Head |
100Km |
100Km |
| Cutter Life |
500K |
500K |
| Cash Drawer |
Extended to IO Panel |
Extended to IO Panel |
| OPTIONAL |
| Card Reader |
MSR, MSR+RFID+NFC, MSR+ibutton |
MSR, MSR+RFID+NFC, MSR+ibutton |
| Barcode Scanner |
| Barcode Scanner |
2D/1D, USB Int, 640*780, Autosense |
2D/1D, USB Int, 640*780, Autosense |
| Physical Dimensions |
Foot Print : 17*16*16.3cm |
Overall (Inc Screen) : 29*20*16.3cm |
